Power Grids

Cast Trays | Power Grids | Fixtures | Cast Baskets | Rotary Retorts | Furnace Parts

Power Grids


  • Multiple designs and patterns to meet your loading requirements
  • Stays flat and outperforms fabricated or one piece cast trays
  • Holds up to heavy loads and rapid thermal cycling
  • Inherent strength of cast components with flexibility of serpentine design
  • Re-buildable by replacing only failed cast components
  • Used in many processes such as vacuum brazing, hardening, annealing, tempering, heat treating and stress relieving
  • Multiple heat & corrosion resistant alloy compositions available
  • Power Grids
  • Multiple tier Power Grid
  • Vacuum Tray

Below are some examples of our Power Grid designs.
Click on the pictures to enlarge.

PGR100-S-3648-800 PGR100-S-3648-801-2L PGR100-S-4848-803-3L
PGR100-P-56DIA-601 PGR100-S-7296-701 PGR100-S-3648-803
Power Grid Assem1
Assem1 PGR100-S-4848-601SP
